FCC Reactor Riser with Feed Cone

  • Hot wall design and fabrication of a FCC external riser with injection feed cone.
  • 1 ¼ Cr – ½ Mo (w/ API-934 restrictions)
  • 3’-9” diameter
  • 81 500 lbs
  • 95’-0” long

Hydrotreating Spherical Reactor

  • Design, calculations, drawing and procurement of a spherical hydrotreating reactor.
  • 1 ¼ Cr – ½ Mo (w/ API-934 restrictions)
  • 22’-4” diameter
  • 205 000 lbs
  • 40’-0” long

FCC Reactor (Hot wall)

  • FCC reactor designed and fabricated per ASME Section 8 and API-934 including VSS internals, cyclone system, DHT, PWHT, external coating, refractory lining and full assembly for boat delivery as a complete unit.
  • 1 ¼ Cr – ½ Mo (w/ API-934 restrictions)
  • 17’-2” diameter
  • 530 000 lbs
  • 105’-0” long

Hydrotreating Reactor

  • Hydrotreating Reactor made of clad material and fabricated with API-934 requirements including DHT, PWHT and external coating.
  • 1 ¼ Cr – ½ Mo w/ 347SS clad
  • 9’-0” diameter
  • 99 500 lbs
  • 44’-0” long
